MAGNAT RV 3

Thương hiệu: |

60.000.000₫

The heart and control center of the RV 3 lies in the audiophile tube preamplifier, which amplifies the incoming signals directly after the input stage. Fans of vinyl will be delighted by the elaborate phono section with its separate inputs for moving magnet (MM) and moving coil (MC) pickups. The RV 3 delivers perfect sound quality at all volumes and excellent compatibility with modern speakers.

The driving force behind the RV 3 is a discrete power amplifier with 400 watts of continuous sine power. The mechanical components and equipment of this exceptional amplifier are state of the art. As solid, customized heat sink and the solid metal caps for the gigantic power supply unit generate a unique and distinctive design, without detracting from the flawless functionality of the device.



Images

Test reports

  • Audio Test<br>08/2014

    Audio Test
    08/2014

  • FAZ Magazin 05 / 2014

    FAZ Magazin 05 / 2014

  • av-magazin.de<br>08 / 2013

    av-magazin.de
    08 / 2013

  • av-magazin.de
08/2013

    av-magazin.de 08/2013

  • HiFi Test <br> 6 / 2013

    HiFi Test
    6 / 2013

  • i-fidelity.net<br>06/2013

    i-fidelity.net
    06/2013

  • LP
06/2013

    LP 06/2013

  • hifi&records <br> 04 / 2013

    hifi&records
    04 / 2013

  • What HiFi <br>09 / 2013

    What HiFi
    09 / 2013

  • Audioreview<br>11-12/2013

    Audioreview
    11-12/2013

  • Plus X Award<br> 2013

    Plus X Award
    2013

  • Plus X Award<br> 2013

    Plus X Award
    2013

Description
Value
Output power / Nominal
20 Hz – 20 kHz, THD < 1.0%
4 Ohm, 2 x 200 W
8 Ohm, 2 x 150 W
Peak
1 kHz, 4Ω: 2 x 350 W
Frequency response
CD/Tuner/Aux/Line/Tape:
20 Hz – 20 kHz (+/-0,2 dB)

Phono: 20 Hz – 20 kHz (+/-0.2 dB)

hono Subsonic Filter: 16 Hz, 18 dB/Oct.

CD/Tuner/Aux/Line/Tape:
5 Hz – 110 kHz (-3.0 dB) 20 Hz – 20 kHz (+/-0.1 dB)
Input sensivity
CD/Tuner/Aux/Line/Tape: 600mV/100kΩ

Phono MC: 0,3mV/470Ω

Phono MM: 3mV/47kΩ
Power consumption
Max 650 W
Mains voltage
230 VAC / 50 Hz
S/N ratio
CD/Tuner/Aux/Line/Tape: 110 dB

Phono MM: 90 dB

Phono MC: 78 dB
Dimensions (WxHxD)
434 x 155 x 360 mm
(410 mm incl. control elements)
Weight
19.5 kg
Color
Black
